Design

• Black ceramic glass with stainless steel flush-fitted trim

Handling

• TwistPad® Fire

Flexibility

• 2x 2x Flex zoness
• 4 induction zones
• Cooking zones: 1 x Ø 400 mmx240 mm, 3.3 KW (max. Power level 3.7 KW) Induction or 2 x Ø 190 mm, 2.2 KW (max. Power level 3.7 KW) Induction; 1 x Ø 400 mmx240 mm, 3.3 KW (max. Power level 3.7 KW) Induction or 2 x Ø 190 mm, 2.2 KW (max. Power level 3.7 KW) Induction
• Cooking zones will be automatically joined or separated based on the shape and size of the cookware placed.

Comfort & Convenience

• PotBoost function for all cooking zones
• PanBoost
• PowerMove
• PowerTransfer
• FryingSensor with 5 temperature settings
• 17 power levels for each cooking zone
• Residual heat indicator: Digital 2-step
• LED display and timer with auto switch off for all cooking zones
• Automatic pan recognition sensor powerManagement Function Automatic safety switch-off Child safety lock Wipe protection function
• ReStart function
• QuickStart - Quick and automatic first pot detection
• Keep warm function for all cooking zones
• Energy consumption display

Integrated Ventilation Downdraft System

• Induction cooktop with fully integrated high-performance downdraft extractor.
• Aesthetically integrated fully flush air intake design with floating, heat resistant glass ceramics element for free movement and placement of cookware.
• Ventilation system with 17 electronically controlled fan power levels and 2 Boost-/Intensive fan power levels (with automatic revert) via TwistPad® Fire user interface.
• Automatic switch-on of ventilation system when a cooking zone is used.
• Sensor-based and cooktop-based, fully-automatic adjustment of power levels via advanced algorithm for maximum convenience.
• 3 possible sensitivity modes of algorithm for maximum convenience (Low-noise oriented, balanced, performance-oriented).
• Automatic delayed shut-off after cooking to erase residual odors after cooking (in specific ultra low-noise fan level, 12min in ducted extraction, 30min in recirculated extraction, can be shut-off manually).
• High-performance, low-noise blower with energy-effcienct BLDC-technology. High extraction rates at very low noises with pleasant noise frequencies through psycho-acoustically and aerodynamically optimized interieur with enclosed, non-visible blower. Highly pressuredrop resistant even with longer and more complex ductings.
• Optionally manual control possible by TwistPad® Fire.
• Extraction performance in ducted extraction (according to EN 61591): min. normal setting 154 m3/h , max. normal setting 500 m3/h , max. Boost-/Intensive setting 622 m3/h .
• Extraction performance in recirculated extraction (according to EN 61591): min. normal setting 150 m3/h , max. normal setting 500 m3/h , max. Boost-/Intensive setting 615 m3/h.
• Noise min. normal setting & max. normal setting: 42 dB  & 69 dB .
• Suitable for ducted or recirculated extraction configuration (incl. differentiated software modes). Respective mandatory installation accessories required:  - Installation kit Z811DU0 for ducted extraction. - Installation kit Z821PD0 for fully ducted and partly-ducted recirculation with cleanAir odor filters (recommended for recirculation extraction against an external wall). Starter kit Z821UD0 for unducted recirculation with cleanAir odor filters (recommended for recirculation extraction against an internal wall or in an island bench).
• - cleanAir odor filters: Lifetime of 360 hours of cooking (non-regenerative).
• - Low-noise filters with optimized psycho-acoustics.
• - Large scale filter surface with high odor reduction capabilities.
• - Optimized odor reduction performance for cooking applications with complex odor molecules (e.g. fish).
• - Convenient one-hand removal of unit via floating glass ceramics handle.
• All parts of the unit are easy-to-clean, fully dishwasher safe and heat resistant.
• (Upper) Liquid collector unit with 200ml of capacity for standard accidental spillages or cooking condensate.
• Integrated, large-scale, high performance stainless-steel grease filters with 12 filtration layers and one black top layer for enhanced aesthetical integration.
• Overall capturing capacity of 900ml (200ml + 700ml).
• Powerful drainage system for spillages that exceed 200ml of liquids.
• Liquid safety collector with additional capacity of 700ml for more severe accidental situations. Dishwasher safe. Easily accessible and detachable from below.
• Watertight blower system.
• - Noise level in ducted extraction (Sound power level according to EN 60704-3): min. normal setting 42 dB  re 1 pW, max. normal setting 69 dB  re 1 pW, max. Boost-/Intensive setting 74 dB  re 1 pW.
• - Noise level in recirculated extraction (Sound power level according to EN 60704-3. ): min. normal setting 41 dB  re 1 pW, max. normal setting 68 dB  re 1 pW, max. Boost-/Intensive setting 72 dB  re 1 pW.
• - Grease filter efficiency (according to EN 61591) 94 %.
• - Easy-to-access and easy-to-remove from above.

Technical Information

• Appliance dimensions: (W x D) 826 mm x 546 mm
• Installation dimensions: (H x W x D) 223 mm x 750 mm x 490 mm
• 80 cm width
• Length wire connection: 110 cm
• Min. worktop thickness: 16 mm
• 7.4 KW total connected load
• Cable included

Planning & Installation Notes

• Suitable for ducted or recirculated extraction configuration (incl. differentiated software modes). Respective mandatory installation accessories required:
• - Z811DU0 required for ducted extraction. Included with the purchase of T58TL6EN2.
• - Z821PD0 for fully ducted and partly-ducted recirculation with cleanAir odor filters. Recommended for extraction against an external wall. Additional ducts are required.  Installation kit Z821UD0 for unducted recirculation with cleanAir odor filters. Recommended for extraction inside the kitchen such as an island bench setting or an internal wall.
• - Installation is possible in island as well as wall oriented configurations.
• - The max. immersion depth is 223mm below glass for top mounted appliances and 227mm for flush installed appliances.
• - The minimum worktop thickness is 16mm for top mounted and flush installed appliances with the standard installation system. Installation in even thinner worktops is also possible with the spare part: 626792.
• - The overall appliance weight is 26kg - the bearing capacity and stability, in the case of very thin worktops in particular, must be supported using suitable substructures. The overall appliance weight and the worktop manufacturer's structural integrity specifications are to be taken into account.
• - The appliance must be freely accessible from below (i.e. for accessing the lower liquid safety collector).
• - Installation kit Z821UD0 for unducted recirculation enables easy and quick installations and can be planned in all worktop depths ≥60cm. For ducted installations - in ducted extraction (Z811DU0) as well as fully or partly ducted recirculation (Z821PD0) - a worktop depth of ≥70cm is required.
• - Installation kit Z821UD0 for unducted recirculation requires a vertical aperture of min. 25mm behind the backpanel of the furniture. Suggested for ideal performance are 50mm.
• - No false floor is necessary below the cooktop with integrated downdraft ventilation system. The drawers and/or shelves in the floor unit must be removable. The backpanel of the floor unit can be kept - only a cut-out for the air outlet is needed (position and size can be taken from the installation instructions).
• - For partly ducted and unducted recirculation extraction installations, a return-flow aperture of ≥400cm² is to be respected in the plinth area. The aperture can be realized via outlet grids, lamella grids or subtly shortened plinths depending on the assortment of the kitchen furniture manufacturer.
• - The air outlet on the backside of the appliance can directly be accessed with a male flat duct element (DN 150).
• - The pressuredrop resistant blower allows longer and more complex ductings up to 8m with three 90° bows while keeping sufficient performance.
• -  In ducted extraction configuration a one-way flap (or backflow trap) with a maximum opening pressure of 65Pa should be installed.
• For ducted extraction configuration: 2 x 2 Battery of directly integrated, high-performance low-noise acoustic filters for significantly lower noise and improved psycho-acoustics.
• - The product complies with the Needle Flame Test (according to IEC 60695-5-11), the V2 flammability class (according to UL94) and the B1 building material class (DIN 4102-1). The starter kit Z821UD0 for unducted recirculation complies with these standards as well.
